CI-292-2 VHF Bent Whip Antenna | 118-137 MHz, BNC, 50W
In stock
CI-292-2 VHF Bent Whip Antenna | 118-137 MHz, BNC, 50W Overview:
The CI-292-2 is identical to the CI-292-1 except that it provides a stainless steel bent-whip radiator which makes it ideal for helicopters and bottom mounting underneath fixed wing aircraft. The CI-292-2 has been re-tested and upgraded to the new RTCA DO-160D environmental requirements and offers the 118 to 137 MHz frequency associated with DO-186A MOPS.
- Designed for single engine piston aircraft
- 118-137 MHz frequencies
- Stainless steel bent-whip radiator
- Vertical polarization
- Omnidirectional radiation pattern
Weight:
0.6 lb
Height:
8.5 in.
Material:
Cast Housing / Stainless steel whip
Finish:
Polyurethane Enamel
Connector:
BNC (female)
Frequency:
118-137 MHz
VSWR:
3.0:1 maximum
Polarization:
Vertical
Radiation pattern:
Omnidirectional
Impedance RF:
50Ω
Power RF:
50W
Temperature:
-55ºC to 85ºC
Altitude:
50,000 ft
Certifications:
FAA TSO
C37d, C38d
RTCA Environmental
DO-160D
Product Codes | |
|---|---|
| Mfr Part No : | CI 292-2 |
| ECCN : | 7A994 |
| PROAPP : | PT2316NM |
| SCHEDULE B CODE : | 8529.10.4000 |
| TSO : | C37d,C38d |
